43inch 4K Multi Point touchscreen.
Technical Specifications
Picture/Display
Diagonal screen size (metric)
108.0  cm
Diagonal screen size (inch)
42.5"  inch
Aspect ratio
16:9
Panel resolution
3840 x 2160
Pixel pitch
0.245 mm
Optimum resolution
3840 x 2160 @ 60 Hz
Display colors
1.07 B
Contrast ratio (typical)
1200:1
Response time (typical)
8  ms
Viewing angle (horizontal)
178  degree
Viewing angle (vertical)
178  degree
Picture enhancement
3/2 - 2/2 motion pull down
3D Combfilter
3D MA deinterlacing
Dynamic contrast enhancement
Motion compens. deinterlacing
Progressive scan
Panel technology
ADS
Operating system
Android 13
Brightness max. (after glass)
450 cd/m²
Brightness max. (before glass)
500 cd/m²
OS UI resolution
UHD
Surface treatments
Anti-Glare coating
Anti-Fingerprint coating
Connectivity
Audio output
3.5mm jack
Video input
HDMI 2.0 (x2)
Display Port1.3 (x1)
USB-C (with 15W power delivery)
Other connections
Micro USB (x1) (OTG)
USB 3.0 A (x2)
USB 3.0 B (x1)
Wifi: 2T/2R 2.4/5/6 GHz
Bluetooth 5.2
OPS (external, removable)
External control
Gigabit LAN RJ45
IR (in/out) 3.5 mm jack
RS232 (in/out) 2.5 mm jack
Convenience
Placement
Landscape (24/7)
Portrait (24/7)
Tilted installation up to 30° backwards
Screen saving functions
Pixel Shift, Low Brightness
Keyboard control
Hidden
Lockable
Remote control signal
Lockable
Signal loop through
IR Loopthrough
RS232
Network controllable
RS232
RJ45
Sound
Built-in speakers
2 x 10W
Power
Mains power
100 ~ 240 VAC, 50/60Hz
Consumption (Typical)
65  W
Consumption (Max)
145 W
Standby power consumption
<0.5W
Energy Label Class
G
Supported Display Resolution
Computer formats
720 x 400, 70Hz
640 x 480, 60,67,75Hz
800 x 600, 60Hz
832 x 624, 75Hz
1024 x 768, 60Hz
1152 x 870, 75Hz
1280 x 720, 60Hz
1920 x 1080, 60Hz
1680 x 1050, 60Hz
3840 x 2160, 30, 60Hz
1920 x 1200, 60Hz
3840 x 2160, 60 Hz, 50 Hz
Video formats
480i, 60Hz
480p, 60Hz
576p, 50Hz
576i, 50Hz
720p, 50, 60Hz
1080i, 50, 60Hz
1080p, 50, 60Hz
3840 x 2160, 30, 60Hz
Dimensions
Set Width
990.0  mm
Set Height
578.2  mm
Set Depth
69.3 mm (Wall mount) / 103.9 mm (external OPS box)  mm
Set Width (inch)
38.98"  inch
Set Height (inch)
22.76"  inch
Wall Mount
200 mm x 200 mm , M6
Set Depth (inch)
2.73" (Wall mount) / 4.09" (external OPS box)  inch
Bezel width
23.4 mm touch black border (T/R/L/B)
Weight
Product with packaging (kg)
20.63  kg
Product with packaging (lb)
45.48  lb
Product without packaging (kg)
17.05 kg
Product without packaging (lb)
37.59 lb
Operating conditions
Altitude
0 ~ 3000 m
Temperature range (operation)
0 ~ 40  °C
MTBF
50,000  hour(s)
Temperature range (storage)
-20 ~ 60  °C
Humidity range (operation)[RH]
20 ~ 80% (without condensation)
Humidity range (storage) [RH]
5 ~ 95% (without condensation)
Multimedia Applications
USB Playback Video
MPEG 1/2 (1080p 60Hz)
MPEG 4 (1080p 60Hz)
H.263 (1080p 60Hz)
H.264 (4K2K 120Hz)
H.265 (4K2K 120Hz)
VP8 (1080p 60Hz)
VP9 (4K2K 120Hz)
USB Playback Picture
JPEG
PNG
BMP
WEBP
USB Playback Audio
AAC
HEAAC
MPEG 1/2/2.5 Layer 3
MPEG 1/2 Layer 1
MPEG 1/2 Layer 2
Internal Player
CPU
Quad Core Cortex A55
GPU
Multi-Core Mali-G52
Memory
4GB DDR3
Storage
32 GB eMMc
Accessories
Included Accessories
Philips logo (x1)
Power supply cable (3 m)
Quick start guide (x1)
Remote control & AAA batteries
AC Switch Cover
RS232 cable (3 m) (x1)
USB A to B cable (3m) (x1)
Wifi Antennas (2 pcs)
CRD32 wifi module
Optional accessories
Open frame kit (BM03751)
Stand
BM05922 (Optional)
Miscellaneous
On-Screen Display Languages
Arabic
English
French
German
Italian
Japanese
Polish
Spanish
Turkish
Russian
Simplified Chinese
Traditional Chinese
Danish
Dutch
Finnish
Norwegian
Portuguese
Swedish
Warranty
3 year warranty
Regulatory approvals
CE
CB
BSMI
FCC, Class A
CU
ETL
IMDA
PSB
RoHS
EnergyStar 8.0
Interactivity
Multi-touch technology
Projected capacitive
Touch points
10 simultaneous touch points
Plug and play
HID compliant
Protection glass
3 mm tempered safety glass
